CSF Radiators Коллектор впускной BMW M3 / M4 (S58) (G8X), комплект 8233

G8X M2 / M3 / M4 “Level-Up” Charge-Air-Cooler Manifold Features (CSF #8233/8233B/8233C)
CONTACT FOR OTHER FINISH OPTIONS

Faster recovery of Intake Air Temperatures (IATs)
~30°F reduction of Intake Air Temperatures (IATs) compared to OEM
Less pressure drop compared to OEM core
Puts less stress on the turbo system and allows more boost to be made at higher target power levels
Ultra strong CNC Billet construction replaces weak plastic tanks with crimped-on gasket sealing core
High performance bar/plate intercooler core by PWR pressure tested to 120psi
OEM cooler is a tube/fin core which is prone to failing at pressures over ~27psi
Top feed port injection w/ included fuel rail (w/ CNC machined block-off caps included for non-use)
Integrated Nitrous/Methanol Injection Ports
Individual ports for each runner for maximum control
Integrated vacuum and parameter pad to measure additional parameters
Easy access to spin-off oil filter
Integrated breather port for easy bleeding of air from the water side of the manifold
Included KIYLEX Thermal Rejection Manifold Spacer
Made from KIYLEX® – A patented revolutionary high-performance final stage polymer
Acts as a thermal barrier that dissipates heat between the cylinder head and intake manifold
Proven to lower intake manifold temperatures by up to 15%: Lowers Intake Air Temps (IATs)
All necessary brackets, hardware, and instructions to install Raw Billet Aluminum Finish (#8233)
Thermal Black Heat Dispersion Powder-Coating Finish (#8233B)
Available in custom colors from the leader in BMW cooling customization (#8233C) viewable at CSF's website
True Plug-and-Play “Drop-in Fit” Installation – Requires Absolutely No Modifications
OEM level of fit and finish
Limited Lifetime Warranty
Applications:

2021+ BMW G80 M3 (incl. Competition) – 6MT & ZF8 Auto
2021+ BMW G82/G83 M4 (incl. Competition) – 6MT & ZF8 Auto
2022+ BMW G81 M3 (incl. Competition) – 6MT & ZF8 Auto
2020+ BMW F97 X3M (incl. Competition)
2020+ BMW F98 X4M (incl. Competition)
2022+ BMW G87 M2 (incl. Competition) – 6MT & ZF8 Auto
OEM Part Number:

BMW: 17 11 8 095 283
